Telemetri

UVSQ-SAT telemetry 2021-09-10

@uvsqsat telemetry 9k6 BPSK – strong signal.

I have used the following hardware and software:

  • RX at aprox 437.019 MHz Wide-USB
  • 26 el UHF LFA X-Yagi (2* 13 el) from InnovAntennas.
  • AlfaSpid RAS az/el rotor
  • LNA Mini-70 from SHF Elektronik
  • LMR-400 coax
  • Airspy Mini
  • SDR-Console v3 with doppler correction of downlink and satellite tracking, rotor control
  • PstRotator for rotor control interface between SDR-Console and RAS controller
  • VB-Cable: virtual audio cable for piping audio from SDR Console to Soundmodem. Set to 96 kHz and 16 bit.
  • Soundmodem G3RUH BPSK9600 v 0.04b at mode BPSK G3RUH 9600bd. Be sure that the BPSK signal is centered ”over” the signal in the spectrum.
  • UVSQsat Decoder v0.6. Data is beeing sent to both SatNOGS network database and MVP Telemetry server.
Kategorier
Telemetri

LEDSAT telemetry 2021-08-23

@S5Lab @ESA__Education LEDSAT telemetry over Sollentuna, Stockholm. Software and hardware used:

  • RX at aprox 435.190.5 MHz Wide-FM bandwidth 12 kHz
  • 2×13 el UHF LFA X-Yagi (InnovAntennas) in vertical polarisation (best RX…)
  • AlfaSpid RAS az/el rotor
  • LNA Mini-70 from SHF Elektronik
  • LMR-400 coax
  • Airspy Mini
  • SDR-Console v3 with doppler correction of downlink and satellite tracking, rotor control
  • PstRotator for rotor control interface between SDR-Console and RAS controller
  • VB-Cable: virtual audio cable for piping audio from SDR Console to Soundmodem. Set to 96 kHz and 16 bit.
  • HS-Soundmodem 1KUNS-PF v0.09b at mode 9600bd
  • GetKISS+ v 1.3.11 from DK3WN – data uploaded to SatNOGS.
  • Kepler from SatNOGS 49069
LEDSAT
Kategorier
Telemetri

Bugsat-1 telemetry 2021-08-19

Data uploaded to @satnogs

Kategorier
Telemetri

EO-88 Nayif-1 telemetry 2021-07-04

One of the best satellites to test your telemetry and supporting software.

  • RX at aprox 145.937 MHz USB bandwidth 3.0 kHz
  • 2×6 el VHF Yagi (Vårgårda) in RHCP or LHCP polarisation
  • AlfaSpid RAS az/el rotor
  • LNA Mini-2 from SHF Elektronik
  • LMR-400 coax
  • Airspy Mini
  • SDR-Console v3 with doppler correction of downlink and satellite tracking, rotor control
  • PstRotator for rotor control interface between SDR-Console and RAS controller
  • VB-Cable: virtual audio cable for piping audio from SDR Console to Nayif-1 software. Set to 96 kHz and 16 bit.
  • Nayif-1 decoding software.

Kategorier
Telemetri

G0MX-1 telemetry 2021-05-27

G0MX-1 telemetry over Stockholm, 2400bd GMSK. Software and hardware used:

  • RX at aprox 437.253 MHz Wide-FM bandwidth 12 kHz
  • 2×13 el UHF LFA X-Yagi (Innov Antennas) in vertical polarisation (best RX…)
  • AlfaSpid RAS az/el rotor
  • LNA Mini-70 from SHF Elektronik
  • LMR-400 coax
  • Airspy Mini
  • SDR-Console v3 with doppler correction of downlink and satellite tracking, rotor control
  • PstRotator for rotor control interface between SDR-Console and RAS controller
  • VB-Cable: virtual audio cable for piping audio from SDR Console to Soundmodem. Set to 96 kHz and 16 bit.
  • HS-Soundmodem v0.27 at mode 2400bd GMSK G0MX1.
  • GetKISS+ v 1.3.9 from DK3WN – data uploaded to SatNOGS.
Kategorier
Telemetri

Delfi-n3Xt Telemetry 2021-05-26

RX of 152 packets @DelfiSpace Delfi-n3Xt satellite, uploaded to DelfiSpace server. See software used in this post:

  • RX at aprox 145.868 MHz USB
  • 2 x 6 el VHF Yagi (Vårgårda) circular polarisation
  • AlfaSpid RAS az/el rotor
  • LNA Mini-2 from SHF Elektronik
  • LMR-400 coax
  • Airspy Mini
  • SDR-Console v3 with doppler correction of downlink and satellite tracking, rotor control
  • PstRotator for rotor control interface between SDR-Console and RAS controller
  • Decoding software DUDe-5.4c
